Sustainable Energy Solutions: Adhesives, Potting, & Encapsulation

Epic S7475 is a two-component polyurethane compound for potting electronic control modules (ECMs) and a wide variety of electronic devices with an operating range of -50C to 130C. The low mixed viscosity of the S7475 allows the material to flow into intricate areas under printed circuit boards and other tight tolerance areas. Another key property of this product is the 4:1 by volume mix ratio which allows the system to be very adaptable for meter mix and dispense processing. The very low hardness of S7475 in combination with the low Tg provides excellent flexibility, therefore allowing delicate surface-mounted devices (SMDs) to expand and contract during thermal cycling and thermal shock. For applications that generate a great deal of heat, S7475 has shown extremely low weight loss at 130C. S7475 is UL 94-V0 recognized at 4.8 mm and is RoHS compliant.

Epic S7253 series of products are two-component, UL 94 V-0 recognized polyurethane compounds designed for electronic applications requiring encapsulation. The low weight loss of the S7253 series at elevated temperatures suggests that this product is suitable for applications that can reach up to 125°C. The S7253 series is currently utilized in a variety of applications, including automotive applications that require thermal cycling between -40°C and 85°C. The S7253 series of products features good thermal conductivity along with good adhesion to various metals and plastics. The S7253 series of products meet RoHS requirements.

Epic S7457 is a two-component polyurethane potting compound designed for electronic potting applications. Epic S7458 was formulated for applications requiring a low Tg, thermal cycling resistance, and low weight loss at 130°C and is designed to pass UL 94 V-0. This premium RoHS-compliant polyurethane has a very soft durometer and is great for applications with constant thermocycling.

Epic S7351 is a two-component, room-temperature cure, polybutadiene-based polyurethane. The S7351 was specifically formulated for electronic modules and is also an excellent candidate for electronic control modules (ECMs). Due to its low hardness and flexibility, the S7351 will not exert stress on delicate surface-mounted devices (SMDs) on printed circuit boards (PCBs) when exposed to extreme thermal cycling typical of outdoor electronics applications. The S7351 is an excellent alternative to rigid systems that do not allow expansion and contraction of delicate components, causing failures. Also, due to the polybutadiene chemistry used in this formula, the product provides excellent high-temperature properties up to 125°C and much-improved chemical resistance.

Epic S7205 is a two-component, black epoxy system designed for coating or encapsulating a variety of substrates. Epic S7205 features a low viscosity and long pot life to provide bubble-free castings. It has excellent chemical resistance and good electrical insulating properties, making it an excellent choice for use in potting applications subjected to the elements, such as charge controllers.
